Gun Drill Machine for Thermocouple

Gun Drill Machine for Thermocouple

The machine adopts gun drilling methods, when drilling, the cutter tool rotating and in feeding , the workpiece is fixed....

Send Inquiry

Gun drill Machine for Thermocouple

Machine Operation:Gun drilling

Component Details:  theromal couple

Machine Specifications:

Technical Items

Parameters

Drilling diameter range

Φ5~Φ30mm

Max.Hole drilling depth

1650mm

Worktable X axis travel

1300mm

Hole length-diameter ratio

100:1

CNC control system:

GSK system



Machine structure:

The machine adopts gun drilling methods, when drilling, the cutter tool rotating and in feeding , the workpiece is fixed.

The workpiece is a plate , Dimension: 1650mm*1275mm

The machine guide rail adopts linear guide rail (Taiwan Hiwin).

CNC system: GSK

The machine is without safety guard .

Drill box : It adopts variable-frequency motor drives the spindle to rotate through synchronous belt and synchronous belt wheel . The spindle rotary speed range is 500-5000r/min, the main motor power is 5.5kw.

Cutter infeed system: It adopts servo motor drive the ball screw structure through elastic coupling , the stepless speed  regulation can be realized.

Oil sealing :The cylinder control oil plug is automatically jacked at the exit of the drilling hole, and the guide sleeve is automatically jacked at the entrance of the drilling hole under the pneumatic control.

Machine mainly parameters:

Specifications

Parameters

Notes

Working capacity

Drilling diameter range

Φ4~Φ30mm



Max.drilling depth

1650mm



Spindle quantity

1



Machine performance

Z axis

Infeed speed range

5~500mm/min

Stepless

Rapid traverse rate

3000mm/min



Infeed motor torque

7.7Nm



Drill box

Rotary speed range

500~5000r/min

Stepless

Motor power

5.5KW

variable-frequency motor

Max.loading weight

2 T



Travel

1000mm



Motor torque

18Nm



Cooling system

Max. Pressure

10MPa

Adjustable

Max.flow

100L/min

Adjustable

Filter accuracy

20μm



Oil tank volume (roughly)

1000L
