Horizontal Deep Hole Gun Drilling Machine

ZSK2102×1500mm Deep Hole Gun Drilling Machine

1. Machine brief:

1.1 Processing Capacity :

Drill range: Φ3~Φ20mm

Workpiece OD range: Φ15~Φ100mm

Max. Drill depth : 1500mm

Max. drilling length to diameter ratio: 100:1

1.2 Gun drill drilling method, single spindle structure, suitable for machining coaxial holes on shaft parts

1.3 During the machining process, the tool and workpiece rotate relative to each other, and the tool feed

1.4 Workpiece clamping:

The front end of the headstock and guide frame spindle is equipped with a cone disc, and the hydraulic system controls the axial movement of the headstock spindle. By using the chamfers of the cone plate and the two ends of the workpiece, the workpiece is automatically clamped and positioned.

1.5 The guide rails used on the machine are linear guides

1.6 CNC system: SIEMENS

1.7 Drill box:

Using a servo main motor to drive the spindle rotation through a synchronous belt and synchronous pulley, stepless speed regulation can be achieved, with a maximum spindle speed of 5000r/min; The front drive of the spindle is conducive to protecting the main motor and facilitating tool change.

1.8 Headstock:

Drive the workpiece to rotate at a constant speed of 117r/min; The spindle can move axially under the control of a hydraulic system, used to tighten or loosen workpieces. The spindle drive is front mounted, which facilitates the loading and unloading of workpieces and helps protect the main motor.

It can be manually moved on the linear guide rail of the workbench, and after being moved into place, it can be manually locked on the workbench by the locking block.

2.Machine main parameters :
